| Delivery system |
Over-the-patient delivery with balanced instrument arms
Over-the-patient delivery with hanging tube instruments |
| Weight (cuspidor, delivery arm, chair, operating light and LCD monitor) |
200 kg (440 lbs) |
| Maximum loads |
Patient chair: 135 kg (300 lbs)
Tray table: 2 kg (4.4 lbs) |
| Power requirements |
100VAC–240VAC |
| Mains frequency |
50/60 Hz |
| Water supply |
Pressure range: 180-900 kPa (26–130 psi)
Flow rate: ≥ 3 l/min
Quality: hardness ≤ 8° dH (1° dH = 200 mg Ca / 3 l water) |
| Air supply |
Pressure range: 550-900 kPa (80-130 psi)
Flow rate: ≥ 55 l/min
Air quality: medical grade, dry and oil-free |
| Mounting |
To be fixed on the floor |
| Colour |
White (RAL 9016) |
