| Generator |
Constant potential, microprocessor controlled, operating frequency 66 kHz |
| X-ray tube |
Toshiba D-041SB |
Focal spot size
|
0.4 mm according to IEC 60336 |
| Cone diameter |
60 mm (2.36 in.)
Rectangular 36 x 45 mm (1.42 x 1.77 in.) |
| Max. symmetrical radiation field |
Ø60 mm at SSD 200 mm
Ø60 mm at SSD 300 mm
according to IEC 806 |
| Total filtration |
min. 2.5 mm Al equivalent at 70 kV
according to IEC 60522 |
| Inherent filtration |
1 mm Al equivalent at 70 kV
according to IEC 60522 |
| Anode voltage |
60, 63, 66, 70kV |
| Anode current |
8, 7, 6, 5, 4, 3, 2 mA |
| Exposure times |
0.01–2 sec. 24 steps |
| SSD (Source-Skin Distance) Standard/Long |
200 mm (8 in.)/300 mm (12 in.) |
| Mains voltage |
100 V~/110-115 V~/220-240 V~, 50/60 Hz |
| Duty cycle |
1:13.5 |
| Electrical classification |
Class I Type B |
| Weight |
total 29 kg (64 lbs)
tube head with standard cone 4.2 kg (9.3 lbs)
tube head with long cone 4.5 kg (10 lbs) |
| Colour |
White (RAL 9016) |
